Industrial Nitrogen Tunnel Freezer For Pork


Availability:

Quantity:



Inquire Add to Basket

Our Industrial Nitrogen Tunnel Freezer ensures rapid, uniform freezing for pork products. It achieves -196°C to lock in freshness, texture, and nutritional value. This freezing equipment is designed for high-capacity production lines, guaranteeing minimal dehydration and superior quality for various pork cuts and processed items.

Model:
LND
Brand:
WUYE
Warranty:
12 months
Voltage:
Customized
Refrigerant:
Nitrogen

iqf freezer Industrial IQF Freezer Nitrogen Tunnel Freezer IQF Freezer For Pork nitrogen freezer

Product Description

、

Our Industrial Nitrogen Tunnel Freezer ensures rapid, uniform freezing for pork products. It achieves -196°C to lock in freshness, texture, and nutritional value. This freezing equipment is designed for high-capacity production lines, guaranteeing minimal dehydration and superior quality for various pork cuts and processed items.

Automatic temperature control

Continuous production

Easy to operate

Save liquid nitrogen

Product name	Liquid nitrogen quick freeze	Temperature	-40℃~0℃
Application	Pasta, fruits and vegetables, seafood, etc.	Quick freezing time	10-15 minutes
Capacity	300-2000kg/h	Structural features	Up and down lifting structure
Mesh belt material	Food grade stainless steel SUS304	Mesh belt width	1000~1600mm

10 minutes quick freezing, -196℃ quick freezing

Liquid nitrogen instantly vaporizes upon contact, extracting heat 5-10 times faster than conventional methods. This forces pork products through the critical ice crystal formation zone (0°C to -5°C) in minutes. The resulting micro ice crystals prevent muscle fiber damage, drastically reducing purge loss during thawing and perfectly preserving the pork's tenderness, color, and natural juices.

Why choose our liquid nitrogen quick freezer?

√

-196°C Ultra-Fast Freezing

Freezing completes in 10-30 minutes

<5% thawing loss, preserves natural juices

Micro ice crystals, perfect muscle structure

High-volume continuous processing

Hygienic lift-up design for easy cleaning

Ensures superior food safety

Fully automated, labor-saving operation

×

-30°C Slow Freezing Process

Requires 6 to 48 hours

Over 30% shrinkage, tough texture

Large, damaging ice crystals

Limited batch capacity, inconsistent quality

Fixed structure, cleaning difficulties

Potential hygiene risks

Manual handling, labor-intensive

Food grade stainless steel

All food-contact surfaces are constructed from food-grade SUS304 stainless steel, known for high strength and superior corrosion resistance. The thickened mesh and shafts enhance durability, ensuring a long service life in demanding meat processing environments.

Up and down lifting structure

The innovative split lifting mechanism allows the entire freezing chamber to be raised. This provides full access for sanitation and inspection, meeting strict HACCP management requirements for meat processing.

Independent fan

Independently controlled stirring fans in each zone maintain precise temperature uniformity. This eliminates turbulent interference and ensures consistent, high-quality freezing results for every pork cut.

Actual production cases

This freezer is ideal for pork cuts, chops, minced meat, and other high-value meats like beef and poultry. It also excels with seafood (tuna, lobster), prepared foods, and delicate pastries. The system is essential for preserving quality in high-volume protein processing lines.
